WLF series dedust turbine crusher

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
LINGLING
Model Number:
WLF
Application:
Powder
Type:
crusher
Machine Type:
Crusher
material:
stainless steel
After-sales Service Provided:
No overseas service provided
Supply Ability
Supply Ability:
3 Set/Sets per Month
Packaging & Delivery
Packaging Details
wood case
Port
shanghai port
Lead Time :
10~30 days

1:Main application:

It mainly applies to chemicals,dyes,additives,animal feed,food,medicine,wood,chemical fiber and low in non-metallic minerals such as the hardness of the crushed material processing,the fineness of 20-200 between the heads of regulation, with high-yield, grain small degree, low noise, low power consumption, easy maintenance, easy to install, and other advantages, especially suitable for oily, viscous, heat-sensitive, such as fiber and low in hardness of the crushed material processing.



2:Work method:

Spindle drive motor and high-speed rtating turbines, tubo-screen with circle on the composition of the broken pieces of grinding, plus mateials from the hopper into the machine in the cavity, the materials in the turbine rotating in the air close to friction and strong. The impact of the turbine blades on the inside, and grinding the leaves and pieces of gap between the ground again.



3:Technical data:

Model

WLF-200

WLF-300

WLF-400

Capacity(kg/h)

60-200

50-300

100-500

Speed of principal axis(r/min)

5600

Size of input granules(mm)

12mm

Fineness of products(mesh)

20-200

Grinding power(kw)

5.5

7.5

11

Dust absorption power(kw)

0.75

0.75

1.1

Kuan fan power(kw)

0.75

Overall size(L*W*H)(mm)

1000*800*1600

1200*850*1780









S1053670_wlf.jpgPackaging Details.jpg
