auger conveyor

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
LINGLING
Model Number:
LS
Material:
Stainless Steel
Voltage:
as consumer requirement
Material Feature:
Heat Resistant
Certification:
iso 9001 certificate
Structure:
Chain Conveyor
Type:
Screw Conveyor
Load Capacity:
as raw material
Dimension(L*W*H):
as machine model
Power(W):
as machine model
material:
stainless steel
After-sales Service Provided:
No overseas service provided
Supply Ability
Supply Ability:
2 Set/Sets per Month
Packaging & Delivery
Packaging Details
wood case
Port
shanghai port
Lead Time :
10-30 days



 Detailed Peoduct Description

LS series screw conveyor improves of the GX type screw conveyor. It adopts the head and tail

bearing moving to outside of the shell, with sliding hanging bearing, dust-proof seal  device,  the machine is in high reliability, good adaptability, easy installation and maintenance.



Main Application:

LS screw conveyor is widely used in various industries, such as building materials, electric power,

chemical industry, metallurgy, coal, machinery, light industry, cereals and food industries,etc.

LS screw conveyor for conveying material requirements: dust, granular and small block materials,

such as: cement, coal, grain, fertilizer, ash, sand etc, and the material temperature is less than 200

degree. The maximum angle may not exceed to 20 degrees.



Technical Parameters:





Conveying elevation: β=450,Rotate speed n=134r/min

Model

LS-10

LS-12

LS-14

LS-16

LS-20

LS-25

Inner diameter of material barrel(mm)

100

120

140

160

200

250

Conveying capacity(t/h1)

Concrete
p=1.25

2.4

4.7

8.3

11.0

21.0

40.0

Coal powder
p=0.6

1.2

2.3

4.0

5.3

10.0

19.2

Carbon
p=0.9

1.7

3.4

6.0

7.9

15.0

28.8

Salt
p=1.2

2.3

4.5

8.0

10.5

21.0

38.4

The above is our technical data. We can also design and manufacture different varieties upon customer's request.







LS1_.jpgPackaging Details.jpg
