granules vacuum conveyor

FOB Reference Price:Get Latest Price
$2,000.00 - $10,000.00 / Set | 1 Set/Sets (Min. Order)
Type:
Vertical Conveyor Other
Load Capacity:
600kg
Model Number:
qvc
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 10 >10
Est. Time(days) 60 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Field installation, commissioning and training, No overseas service provided
Place of Origin:
Jiangsu, China
Brand Name:
LL brand
Material:
Stainless Steel
Voltage:
220~600v
Material Feature:
Fire Resistant
Certification:
iso 9001 and CE
Structure:
Conveyor System
Dimension(L*W*H):
290*850mm
Power(W):
2.2kw
material:
stainless steel
Supply Ability
Supply Ability:
2 Set/Sets per Month
Packaging & Delivery
Packaging Details
wood case
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 60 To be negotiated



Specifications

Compared with traditional oil seal blade vacuum pump conveying solution, the injection vacuum pump used in conveyors are more ch

Vacuum Conveyor is developed for flexible bulk/powder conveying.

1. Advantage:

Compared with traditional oil seal blade vacuum pump conveying solution, the injection vacuum pump used in conveyors are more flexible, more clean.

2. Working principle:

First the vacuum is generated in the air injection pump, and powder material is sucked in the conveyor tank, the powder is separated from the air by the filter and stay in the conveyor tank, when the tank is full filled, the pump stop and discharge valve is opened for powder material discharge. All the process is controlled by the controller.

3. Features:

  • Vacuum conveying in close pipeline, no leakage, no cross contamination.
  • Low energy consumption
  • Well static electricity elimination.
  • Ex-provffe type as an option
  • Easy to install and cleaning
  • In accordance with GMP
  • Made of ANSI 304/316L Stainless Steel

4. Applications:

  • Pharmaceutical industry: tablet, granulate, capsule, pills
  • Food industry: additive, surge, coffee, milk powder, flakes, pasta
  • Chemical industry: plastic particles, dye material, rubber powder, organic bulk material......
  • Other industry: small parts, mineral powder, herbs......

Model

Coveying capacity(kg/h)

Air consumption

(L/min)

Gas pressure

Mpa

Overall size

QVC-1

350

180

0.4-0.6

Φ140*560

QVC-2

700

360

0.4-0.6

Φ213×720

QVC-3

1500

720

0.4-0.6

Φ290×850

QVC-4

3000

1440

0.4-0.6

Φ420*1150

QVC-5

6000

2880

0.4-0.6

Φ420*1150

QVC-6

9000

4320

0.4-0.6

Φ420*1350
