Pulse dust absorption mini pulverizer

FOB Reference Price:Get Latest Price
2 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
LINGLING
Model Number:
WFJ
Application:
Powder
Type:
crusher
Machine Type:
Crusher
material:
stainless steel
After-sales Service Provided:
No overseas service provided
Supply Ability
Supply Ability:
2 Set/Sets per Month
Packaging & Delivery
Packaging Details
wood case
Port
SHANGHAI
Lead Time :
30 Days

Pulverizer  Machine model WFJ WFJ main engineMain application:

    Its features are compact in design, reasonable in structure. It has air choosing type and has no sieve or screen. Being installed grading mechanism inside the machine, the crushing and grading can be finished at the same time. When use negative pressure to transport in the operation of crushing, the heat produced from the chamber will be removed continuously. Therefore, it is also suitable for crushing thermal sensitive raw materials. The scope of application of machine is wide. Its productive process is continuous and its size of granule can be adjusted. It can crush and grade many raw materials, such as chemical products. foodstuff, medicines, cosmetic, dyestuff, resin, shell materials and so on. This machine has reached international advanced level.

Working principle:
    Material is fed into the crushing chamber through a screen conveyor, cut and crushed by highs-speed rotating blade and conveyed to the cyclone separator, and the dust is filtered and recovered by dust collector through a bag. Having no dust flying during production, it can improve utilization rate of the material and reduce the cost of enterprise.



Technical Data:





ModelWFJ-15WFJ-20WFJ-30WFJ-60
Capacity (kg)30-20050-30050~800100~1200
Feed size (mm)<10<12<10<10
Output size (mesh)80-500 (adjustable)
Motor power (kw)13.517.542.8570.45
Spindle speed (rpm)6000480036502900
Weight (kg)980130020003500
Overall size(L*W*H)(mm)4200*1200*27004700*1250*29006640*1300*39607500*2300*4530
